Split QWERTY

Here’s an example of a much larger grid, a full-QWERTY layout for a split keyboard like an ErgoDox, Voyager, Advantage360, etc

A screenshot of the 2x2 grid

Notes:

  • The default view that contains the grid is 1024x768, picked arbitrarily because it’s large enough for most grids but small enough for laptop screents. This grid is too big for it, so we have to set gridMaxWidth to wider.
  • Actions set with key=nil and empty=true are totally blank spaces on the board, which let us make that middle space between the hands.
local ergoDoxGrid = {
  {
    -- Left hand top row
    spoon.GridCraft.Action.new { key = "q", application = "Safari" },
    spoon.GridCraft.Action.new { key = "w", application = "Mail" },
    spoon.GridCraft.Action.new { key = "e", application = "Messages" },
    spoon.GridCraft.Action.new { key = "r", application = "Photos" },
    spoon.GridCraft.Action.new { key = "t", application = "FaceTime" },

    -- Spacer
    spoon.GridCraft.Action.new { key = nil, empty = true },
    spoon.GridCraft.Action.new { key = nil, empty = true },

    -- Right hand top row
    spoon.GridCraft.Action.new { key = "y", application = "Calendar" },
    spoon.GridCraft.Action.new { key = "u", application = "Contacts" },
    spoon.GridCraft.Action.new { key = "i", application = "Maps" },
    spoon.GridCraft.Action.new { key = "o", application = "Notes" },
    spoon.GridCraft.Action.new { key = "p", application = "Reminders" },
  },
  {
    -- Left hand middle row
    spoon.GridCraft.Action.new { key = "a", application = "Calculator" },
    spoon.GridCraft.Action.new { key = "s", application = "Dictionary" },
    spoon.GridCraft.Action.new { key = "d", application = "Chess" },
    spoon.GridCraft.Action.new { key = "f", application = "TextEdit" },
    spoon.GridCraft.Action.new { key = "g", application = "Preview" },

    -- Spacer
    spoon.GridCraft.Action.new { key = nil, empty = true },
    spoon.GridCraft.Action.new { key = nil, empty = true },

    -- Right hand middle row
    spoon.GridCraft.Action.new { key = "h", application = "System Settings" },
    spoon.GridCraft.Action.new { key = "j", application = "Activity Monitor" },
    spoon.GridCraft.Action.new { key = "k", application = "Console" },
    spoon.GridCraft.Action.new { key = "l", application = "Terminal" },
    spoon.GridCraft.Action.new { key = ";", application = "Disk Utility" },
  },
  {
    -- Left hand bottom row
    spoon.GridCraft.Action.new { key = "z", application = "Font Book" },
    spoon.GridCraft.Action.new { key = "x", application = "Music" },
    spoon.GridCraft.Action.new { key = "c", application = "System Information" },
    spoon.GridCraft.Action.new { key = "v", application = "Migration Assistant" },
    spoon.GridCraft.Action.new { key = "b", application = "News" },

    -- Spacer
    spoon.GridCraft.Action.new { key = nil, empty = true },
    spoon.GridCraft.Action.new { key = nil, empty = true },

    -- Right hand bottom row
    spoon.GridCraft.Action.new { key = "n", application = "Stocks" },
    spoon.GridCraft.Action.new { key = "m", application = "Home" },
    spoon.GridCraft.Action.new { key = ",", application = "Clock" },
    spoon.GridCraft.Action.new { key = ".", application = "Finder" },
    spoon.GridCraft.Action.new { key = "/", application = "App Store" },
  },
}

local ergoDoxConfig = spoon.GridCraft.Configuration.new()
-- Make sure the grid is wide enough for the ErgoDox layout
ergoDoxConfig.gridMaxWidth = 2048

spoon.GridCraft.Grid.new(
-- The hokey to invoke this is ctrl-shift-f11
  { "ctrl", "shift" },
  "f11",
  ergoDoxGrid,
  "GridCraftErgoDoxQwertyExample",
  ergoDoxConfig
)
